A54/4L560 V-Belt
Description
A / 4L Section V-Belt — Classical & Light-Duty Drive Belt
- Top Width: 1/2" (0.500")
- Height / Depth: 5/16" (0.313")
- Construction: Classical Wrapped — fabric-covered outer surface
- HP Range: 1/4 – 10 HP
- Minimum Sheave OD: 3.0"
- Length Basis: A-section: inside circumference (OC = IC + 2") | 4L: outside circumference ÷ 10
The A/4L-section V-belt is the most widely used classical drive belt in HVAC, industrial, and commercial equipment. Its 1/2" top width and 5/16" depth deliver quiet, reliable power transfer from fractional to 10 HP. Fabric-wrapped construction protects against oil, heat, and abrasion for long service life. A-section belts are ideal for fans, pumps, compressors, and general-purpose drives.
Specifications
Name
S-VB-A54
Product Type
Belts
Display Name
A54/4L560 V-Belt
Belt Profile
A / 4L
Inside Circumference (Inches)
54
Outside Circumference (Inches)
56
Cogged
No
